MAINTENANCE MANUAL
GAS VENT VALVE
C422425 • C422685 • C422695 • C422705 • C423095 • C423155
INDUSTRIAL PRODUCTS GROUP Revision 1.1 10/15/2004 Page 12
D. Connect the field wiring for the solenoid and position indicating switch (when applicable) to their
assigned terminals on the terminal block. Torque the wire terminal screws to 7 to 10 pound-
inches (0,8 to 1,1 Nm). Install an approved stopping block within 18 inches of the conduit entry
port.
E. Re-install the terminal cover with the screws and washers. Tighten the screws to 70 to 90
pound-inches (8 to 10 Nm).
F. Connect the grounding wire and torque the grounding terminal bolt to 35 to 40 pound-inches
(4 to 4,5 Nm).
5. Adjustments
No field adjustments are required.
