Parts
1.
Beverage Refrigerator Control Panel
7.
Wine Refrigerator Control Panel
2. Beverage Refrigerator Internal Fan
8.
Wine Refrigerator Internal Fan
3. Beverage Refrigerator
Wire Shelves (4)
9. Wine Refrigerator Wooden Shelves (6)
4. Door Handle (2)
1
0. Glass Door
5. Beverage Refrigerator Door Lock Latch
6. Front Vent
11. Wine Refrigerator Door Lock Latch
12. Leveling Legs (4)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
13. Beverage Refrigerator Lock
14. Wine Refrigerator Lock
BOTTOM BACK SIDE
15
16
15. Refrigerator Compressor
16. Drip Tray (non-removable)
To Next Page
