2010 Edition 1 Page 17
6.0: TORQUE SETTINGS
Torque explained: If no suitable Torque Wrench is available a Torque of 5 lbf.ft can be obtained by ap-
plying a force of 5lb, with a Spring Balance, to the end of a spanner, 1 Foot in length.
IMPORTANT: For all other torque settings, refer to the specific manufacturers information
bundled with this manual, or alternatively, refer to the specific manufacturers website for
further information.
7.0: NOTES
Whyte Adjustable Dropout System Nm lbs.ft
M6 x 14mm Pivot Screw 13 (min) - 15 (max) 9.5 (min) - 11 (max)
M6 x 16mm Clamping Screws 13 (min) - 15 (max) 9.5 (min) - 11 (max)
Whyte Rear Derailleur Hanger Nm lbs.ft
M4 x 8mm Countersunk Head Capscrew 2.3 (min) - 2.8 (max) 1.7 (min) – 2.1 (max)
WHYTE Service Manual
