7
Operating handle
Lower blade lock lever
Upper xed guard
Lower rotating guard
Blade bolt cover
Fence
Base plate
Rotating mitre table
Mitre table lock latch
Mitre table lock handle
Mitre scale
Mounting hole (x4)
Extended fence for bevel cutting
Table extension (x2)
Work clamp lock knob
Work clamp
Bevel lock lever
Slide rod
Dust extraction port
Dust bag
Carry handle
Release knob
Slide rod lock knob
Spindle lock button
On/off switch
Laser switch
Laser guide
Bevel scale (See Fig. S4)
Saw blade (See Fig. T2)
M5 Hex key for extended fence (See Fig. G1-1)
M8 Hex key for blade (See Fig. T3)
1
3
2
4
6
5
7
11
17
21
26
13
19
24
23
28
29
30
9
8
10
14
20
25
12
18
22
27
ACCESSORIES
M5 Hex key for extended fence 1
M8 Hex key for blade 1
Table extension 2
Work clamp 1
Dust bag 1
Blade (210mm x 24T) 1
We recommend that you purchase your accessories from the same store that sold you the tool. Refer to the accessory
packaging for further details. Store personnel can assist you and offer advice.
15
31
16
