Wickes CSD36Y1 - Collet Locking Sleeve Operation; Removing Bits and Accessories; On;Off Switch

11
Pull the collet locking sleeve (1) backward. Fully insert
the desired bit into the chuck and release the collet
locking sleeve (1). The collet accepts only standard 1/4”
hexagonal shank accessories with power groove.
NOTE: Do not use this tool as a drill. Tools equipped
with shut off clutches are not designed for drilling
applications.
The clutch can shut off automatically and without
warning. Attempting to restart drilling after shut-off
has been reached can cause the tool to twist out of your
hand until the clutch again reaches shut off.
NOTE: Do not attempt to insert quick change type drill bits
into this chuck.
NOTE: Try to pull the bit after releasing the collet locking
sleeve to make sure the bit is fully locked.
1. COLLET LOCKING SLEEVE (See Fig. C)
OPERATION
Fig. C
Pull the collet locking sleeve (1) backward. Take the tool out of the chuck and release the collet locking sleeve (1) .
2. REMOVING A BIT HOLDER, SOCKET OR SCREWDRIVER BIT
Depress the on/off switch (5) to start and release to stop
your driver.
3. ON/OFF SWITCH (See Fig. D)
Fig. D
1
22
22
Redash Battery Temperature
Protection
The temperature of battery
pack is less than 0
o
or
more than 40
o
.
