1.4.1. Technical Data
1.4.1.1. WIDOS ASM 315 WM General Data
Dimensions of main pipes: outside-Ø = 90 - 315 mm (optional)
Dimensions of branch pipes: outside-Ø = 63 - 250 mm (optional)
Material: PP, PE 80, PE 100
Wire cross section: 1.5 mm²
Emissions - Noises exceeding 80 dB (A) may occur; during drilling it is
obligatory to wear ear protection!
- When using the named plastic materials and when welding
below 260 °C no toxicant damp arises.
Ambient conditions in the
welding area
- take care for cleanness (no dust at the welding area)
- if secured by an appropriate measurement that allowed
conditions for welding are indicated, it is possible to work
in any outside temperature condition as far as the welder
is not constrained in its manual skill.
- avoid humidity, if necessary use a welding tent
- avoid strong sun rays influence
- - protect from wind, shut the pipe ends
1.4.1.2.
Heating element with control unit
Heating area: 300 x 400 mm
Power: 3,2 kW
Current: 14 A (± 10 %)
Voltage: 230 V (± 10 %)
Frequency: 50 Hz
Fuse protection: 16 A
Surface: anti-stick coated
Interface heating element / control unit: 10-pole plug socket
Attached elements: - electronic temperature control
- on / off switch with control lamp
- connecting cable with plug
1.4.1.3.
Drilling machine
Power: 1,05 kW
Current: 4.5 A (± 10 %)
Voltage: 230 V (± 10 %)
Frequency: 50 Hz
Fuse protection: 16 A
Attached elements: - on / off switch
- fixing device
- Start button
- connecting cable with plug
