The use of liquid damping is always recommended for
temperatures near the dew point (±1 °C around 0 °C).
EN
7. Commissioning, operation
The bimetal thermometer must be earthed via the process
connection!
When screwing the instruments in, the force required to do this
must not be applied through the case! but only through the spanner
flats provided for this purpose and using a suitable tool.
When mounting a bimetal dial indicating thermometer that can be
rotated and swivelled, the specific instructions must be followed. In
order to set the indicator to the desired position, the following steps
must be taken:
1.
The lock nut or union nut must be loosened at the process
connection.
2.
The hexagon bolts and slotted screws at the swivel joint must be
loosened.
WIKA operating instructions models 53, 54, 55 (ATEX) 15
