EN
12968065.06 06/2019 EN/DE/FR/ES
10 WIKA operating instructions model 55
3.7 Labelling, safety marks
Product label (example)
Model
Year of manufacture
Serial number
Before mounting and commissioning the instrument,
ensure you read the operating instructions!
Do not ll the instruments with lling liquid subsequently.
Thermometer
Model
TG53 + option ATEX
14001455
year 2016
WIKA Alexander Wiegand SE & Co. KG
63911 Klingenberg / Germany
WIKA Alexander Wiegand SE & Co. KG
Thermometer
63911 Klingenberg / Germany
year “Jahr”
“Artikelnr.”
Model
“Model” + option ATEX
3. Safety

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the WIKA 55 Series and is the answer not in the manual?

WIKA 55 Series Specifications

General IconGeneral
TypeBimetallic thermometer
Case MaterialStainless steel
Accuracy±1% of full scale
Temperature Range-70°C to +540 °C
Connection1/2" NPT
Window MaterialGlass
Scale DivisionDependent on temperature range
Dial Size63 mm, 80 mm, 100 mm, 125 mm, 160 mm
