EN
12968065.06 06/2019 EN/DE/FR/ES
WIKA operating instructions model 55 5
2. Design and function
2.1 Overview
Case
Stem
Dial
Adjustable stem and dial version
Pointer
Process connection
2. Design and function

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the WIKA 55 Series and is the answer not in the manual?

WIKA 55 Series Specifications

General IconGeneral
TypeBimetallic thermometer
Case MaterialStainless steel
Accuracy±1% of full scale
Temperature Range-70°C to +540 °C
Connection1/2" NPT
Window MaterialGlass
Scale DivisionDependent on temperature range
Dial Size63 mm, 80 mm, 100 mm, 125 mm, 160 mm
