Page #82 background image
ES
12968065.06 06/2019 EN/DE/FR/ES
82 WIKA manual de instrucciones modelo 55
9. Datos técnicos
Termómetro bimetálico, modelo 55
Elemento de medición Espiral bimetálico
Diámetro nominal 63, 100, 160
Construcción del aparato
Modelo A5x
Modelo R5x
Modelo S5x
Conexión dorsal (axial)
Conexión inferior (radial)
Conexión dorsal, caja giratoria y orientable
Temperatura ambiente
admisible
-50 ... +60 °C
Rango de servicio
Carga a largo plazo (1 año)
A corto plazo (máx. 24 h)
Rango de medida (EN 13190)
Rango de indicación (EN 13190)
Caja, anillo Acero inoxidable 304SS
Bulbo, conexión a proceso Acero inoxidable 316SS
Tipo de protección IP65 según IEC/EN 60529
IP66, lleno de líquido
Para más datos técnicos véase las hojas técnicas TM 55.01 y la
documentación de pedido.
