6 WIKA operating instructions flow switch, model FSD-3
EN
14153887.01 09/2016 EN/DE/FR
2.2 Functional description
The ow switch works by the calorimetric principle and is used to convert the ow rate into an electric signal. The
instrument shows the ow rate in per cent on the digital display.
Optionally, the instrument measures the medium temperature.
The instrument can output up to 2 output signals as parameterised.
■
Switching signal for ow limit values
■
Switching signal for temperature limit values
■
Switching signal for diagnostic function
■
Analogue signal ow
■
Analogue signal temperature
2.3 Scope of delivery
■
Flow switch
■
Operating instructions
■
Accessories process connection (optional)
■
Further certicates (optional)
Cross-check scope of delivery with delivery note.
2. Design and function
