3. Specications
3.5 Accuracy data
Accuracy, analogue signal
≤ ±1.0 % of span
Including non-linearity, hysteresis, zero oset and end value deviation (corresponds to measured error
per IEC 61298-2). Calibrated in vertical mounting position with process connection facing downwards.
Non-linearity: ≤ ±0.5 % of span (BFSL, IEC 61298-2)
Long-term drift:≤ ±0.2 % of span (IEC 61298-2)
Accuracy, switching output
Switch point accuracy: ≤ ±1 % of span
Adjustment accuracy: ≤ ±0.5 % of span
Display
≤ ±1.0 % of span ± 1 digit
Temperature error in rated temperature range
■
typical: ≤ ±1.0 % of span
■
maximum: ≤ ±2.5 % of span
Temperature coecients in rated temperature range
Mean TC zero point: ≤ ±0.2 % of span/10 K (typical)
Mean TC span: ≤ ±0.1 % of span/10 K (typical)
3.6 Reference conditions
Temperature: 15 ... 25 °C (59 ... 77 °F)
Atmospheric pressure: 950 ... 1,050 mbar (13.78 ... 15.23 psi)
Humidity: 45 ... 75 % r. h.
Nominal position: Process connection lower mount (LM)
Power supply: DC 24 V
Load: see output signals
