In general
Congratulations on your new WIKING woodburning stove. We are pleased that you have cho-
optimum operation and safety, we recommend that the installation should be carried out by an
retailers, visit www.wiking.com under “Retailer locations”.
Safety
The installation of your WIKING woodburning stove must always comply with all European,
national and local building regulations. The installation must be carried out in accordance with
the instructions in the installation and user manuals and subsequently registered with the local
authorities. Upon installation, the chimney sweep must approve the installation before you can
start using the woodburning stove. All WIKING woodburning stove packaging material must be
handled in accordance with local waste management regulations.
Room requirements
Always ensure a supply of fresh combustion air to the room where the stove is to be installed.
The woodburning stove uses approx. 8-21 m
3
of air per hour. A window that can be opened
valve/grate. In newly built/airtight dwellings, we recommend that a fresh air system should be
installed for the direct supply of external air to the combustion. This fresh-air system may be
bought separately.
withstand the weight of the stove and the chimney. The weight of the chimney should be cal-
culated according to its dimensions and height.
Technical measures and data
Test results from nominal test EN 13240
4.9 kW
Flue gas temperature EN 13240 measurement point 295ºC
Flue gas temperature measured in the outlet socket 326ºC
5.2 g/s
78 %
68 %
PM 18.2 mg/m
3
OGC 66 mg/m
3
NO2 114 mg/m
3
CO at 13% O2 1125 mg/m
3
CO at 13% O2 0.09 %
103
A
Test result based on NS 3058
Particle emissions 3.05 g/kg
