1. Turn the calibrator ON and set the toggle switch to

CHIRP. The calibrator emits a 100ms long tone at 40kHz

(+/- 10Hz) every 500ms. The amplitude of the tone is

104dB SPL (+/- 3dB) at 10cm.

2. Enter Live Mode on the Echo Meter Touch and place the

calibrator within 20 meters to assure the signal can be

received.

3. With the calibrator chirping, you can test trigger settings

and monitoring modes.

WARNING! Do not place the Ultrasonic Calibrator near your

ears. In CHIRP mode, the calibrator emits a 40 kHz signal at over

100 dB SPL. Prolonged exposure to high intensity ultrasonic

signals may cause permanent hearing loss at audible

frequencies.

Specifications

5.1 Physical

Echo Meter Touch

(original)

Echo Meter Touch 2

and 2 Pro

Length w/o Lightning:

1.8 inches (46 mm)

1.4 inches (35mm)

Width:

1.9 inches (48 mm)

Thickness:

0.47 inches (12 mm)

.3-.6 inches(7-16mm)

Weight:

1.1 ounces (31 g)

0.7 ounces (20g)

Material:

Anodized Aluminum

Polycarbonate/ABS

Environmental:

Weather resistant but avoid rain
