1. Handle
2. Control panel
3. Air outlet
4. Air inlet with lter
5. Exhaust hose with adapter
6. Power cord hanger
7. Exhaust air outlet
8. Water stopper (plug inside
9. Casters
10. Cap – hole cover
11. Wall adapter
12. Exhaust hose
13. Drainage hose
14. Remote control
15. Foam (extension)
16. Foam with hole for exhaust hose
17. Filter
5
8
7
9
6
4
1
2
3
4
11
10
12
13
14
15
16
17
PARTS
This unit can easily be moved from one room to another. In doing so keep this in mind:
• The air conditioner must stand upright on an even surface.
• Do not position near bath, douche or other permanent wet or damp area.
• Keep for free air circulation at least 50 cm free from any obstacle or curtains.
1
2
a
2
b
4
5
3
a
3
b
