Digital Piano Set-up Guide...............Continued
2. Follow the illustration below and finish off the set-up procedures.
Caution: When setting up the piano, please use the screws supplied and avoid using the
unspecified screws which may damage the piano body or causing the lost of
stability.
Parts required in this
step:
7. Hand screws x 4
8. Screws x 8
9. Screw caps x 8
A. Put the foot pedal unit(6) in between the left and right legs components (3&4), use 4 pieces
of screws (2 on each side) to stable the legs onto the foot pedal unit.
(Make sure the direction of the placement is correct before screwing)
8
8
8
8
7
7
9
9
9
9
4
To Next Page
