Holding register
(Protocol)
Name Data type Scale & unit Elements Access* Added
40003
(2)
Switch box type ENUM 0. SC
1. SC...FC
2. SCe
3. CC
4. CC...FC
5. CCe
6. SCe NWB
7. CCe NWB
8. EC
9. ECe
10. ECe NWB
R 31,000
40014
(13)
Bus command timer ENUM 0. -
1. Off
2. Set
3. Active
4. Reset
5. Manual
RW 31,000
40015
(14)
Drives on/off BOOL RW 31,000
40025
(24)
Control mode ENUM 0. p-c
1. dp-c
2. dp-v
3. dT-c
4. dT-v
5. n(TV)
6. n(TR)
7. n(TP)
8. n(TA)
9. n-c
10. fill
11. empty/drain
12. FTS
13. cleans/day
14. cleans/
month
R 31,000
40026
(25)
Current value INT16 0.1 bar
0.1 m
0.1 K
0.1 °C
1 cm
1 min
0.1 h
0.1 psi
R 31,000
40041
(40)
Pump 1 mode ENUM 0. Off
1. Hand
2. Auto
RW 31,000
40042
(41)
Pump 2 mode ENUM 0. Off
1. Hand
2. Auto
RW 31,000
40043
(42)
Pump 3 mode ENUM 0. Off
1. Hand
2. Auto
RW 31,000
40062
(61)
Switch box state BITMAP 0: SBM
1: SSM
R 31,000
