Assembling the suspension unit
E:\shares\Baprod\BA\subtec_m\appendix\us\sewage\suspension_unit.fm E-9
Fig. E-6: Assembling the suspension unit
Cover cap (8)
Stud (7 short)
Guide holder (1) / shaft mounting
Securing set 1
Guide element (4)
Stud (10 long)
Clamp (2)
Securing set 2
Guide holder (1) / pipe extension (9)
Flat seal
Coupling flange (A)
Gasket (B)
Stud (6)
Coupling base (3)
Securing set 3
Foundation frame (5) – optional
