Wilo HC 20.1 E3 Series - Scope of Delivery; Accessories; Transportation and Storage; Delivery

Transportation and storage en
Installation and operating instructions Wilo Motor HC 20.1 + EMU FA, Rexa SUPRA, Rexa SOLID 15
Example: Wilo-EMU FA 10.82E + HC 20.1-4/22KEx-E3
Wilo-Rexa SUPRA-V10-736A + HC 20.1-4/22KEx-E3
Wilo-Rexa SOLID-Q10-345A + HC 20.1-4/22KEx-E3
A
Material version:
A = standard version
B = corrosion protection 1
D = abrasion protection 1
X = special configuration
Motor type key
HC
Self-cooling motor with separate cooling circuit
20
Size
1
Internal code figure
4
Number of poles
22
Package length in cm
K
Seal version
Ex
Ex-rated
E3
IE-efficiency class (derived from IEC60034-30)
4.8 Scope of delivery
ƒ Pump with free cable end
ƒ Cable length per customer request
ƒ Mounted accessories, e.g. external pencil electrode, pump support foot, etc.
ƒ Installation and operating instructions
4.9 Accessories
ƒ Suspension unit
ƒ Pump support foot
ƒ Special versions with Ceram coatings or special materials
ƒ External pencil electrode for sealing chamber control
ƒ Level control devices
ƒ Fixation accessories and chains
ƒ Switchgear, relays and plugs
5 Transportation and storage
5.1 Delivery
After receiving the shipment, this must be checked immediately for defects (damage,
completeness). Defects must be noted on the freight documentation! Furthermore, de-
fects must be notified to the transport company or the manufacturer immediately on
the day of receipt of shipment. Subsequently notified defects can no longer be asser-
ted.
5.2 Transport
WARNING
Standing under suspended loads!
Never allow anyone to stand under suspended loads! Danger of (serious) injuries
caused by falling parts. Loads may not be carried over work places where people are
present!
WARNING
Head and foot injuries due to a lack of protective equipment!
Danger of (serious) injuries during work. Wear the following protective equipment:
• Safety shoes
• Safety helmet must be worn if lifting equipment are used!
NOTICE
Use only properly functioning lifting equipment!
Use only properly functioning lifting equipment to lift and lower the pump. Ensure
that the pump does not become jammed during lifting and lowering. Do not exceed
