ENGLISH
1. General
Installation and service by qualified personnel only
1.1 Applications
The multistage selfpriming pump is suitable for clear or slightly muddy
water, industrial water, condensate, water/glycol mixtures up to a ratio
of 35 % glycol as well as other liquids free from mineral oil and without
abrasives or long-fibred substances. Specially suited for use in conjunc-
tion with rain water utilization.
The main areas of use are in rain water utilization systems, water
supply installations, in industrial circulation systems, in process tech-
nology, in cooling water systems and in washing and sprinkler
installations.
Selfpriming pumps must not be directly connected to the
public water supply system.
1.2 Technical description
1.2.1 Performance and electrical data
Single phase voltage: 1 ~ 230 V (± 10 %) / 50 Hz or
Three phase voltage: 3 ~ 230 / 400 V (± 10 %) / 50 Hz;
Motor power: see rating plate,
Maximum current: see rating plate,
Fluid temperature: +5 °C to +35 °C
Max. permissible working pressure: 8 bar,
Min./Max. permissible inlet pressure: –0.8/4 bar,
Max. suction head (SH): 8 m
Max. ambient temperature: 40 °C,
Protective system: IP 54.
Other voltages/frequencies are optional and/or available on request.
When pumping viscous fluids (e.g. water/glycol mixtures) adjust the
pump data to allow for the higher viscosity.
Only use branded glycol mixtures with corrosion inhibitors and follow
the manufacturers instructions.
For dimensions see table and Fig. 4.
7
1.2.2 Series specifications
MC 3 05 - EM / XX
MC MultiCargo
(Multistage horizontal
centrifugal pump) design
Flow rate at optimal
efficeny Q [m
3
/h]
Number of impellers
Main voltage
DM 3 ~ 230/400 V
EM 1 ~ 230 V
Manufacturer's key
Pump Pump unit
Model Dimensions
H H1 L L1 L3 D1 D2 D3
1~230 V 3~400 V 1~230 V 3~400 V
MC mm
304 216 192 90 423 253 157.5 R1 R1 PG 13.5 PG 11
305 216 192 90 447 277 181.5 R1 R1 PG 13.5 PG 11
604 216 192 90 423 253 157.5 R1 R1 PG 13.5 PG 11
605 224 206 90 472 277 181.5 R1 R1 PG 13.5 PG 13.5
When ordering spare parts, please give all the information of the rating plate.
