7
ENGLISH
1. General
Installation and service by qualified personnel only
1.1 Applications
The pump is suitable for clear water, industrial water, condensate,
w
ater/glycol mixtures up to a ratio of 35 % glycol as well as other
liquids free from mineral oil and without abrasives or long-fibred sub-
stances. Specially suited for use in conjunction with rain water utilization.
The main areas of use are in water supply installations, as a boiler
f
eed pump, in industrial circulation systems, in process technology,
in cooling water systems, in fire extinguishers and in washing and
sprinkler installations.
1.2 Technical description
1
.2.1 Performance and electrical data
Single phase voltage: 1 ~ 230 V (± 10 %) / 50 Hz or
Three phase voltage: 3 ~ 230 / 400 V (± 10 %) / 50 Hz;
Motor power: see rating plate,
Maximum current: see rating plate,
Fluid temperature: +5 °C to +35 °C
Max. permissible working pressure: 10 bar,
Max. permissible inlet pressure: 6 bar,
Max. ambient temperature: 40 °C,
Protective system: IP 54.
Other voltages/frequencies are optional and/or available on request.
When pumping viscous fluids (e.g. water/glycol mixtures) adjust the
pump data to allow for the higher viscosity.
Only use branded glycol mixtures with corrosion inhibitors and follow
the manufacturers instructions.
For dimensions see table and Fig. 3.
When ordering spare parts, please give all the information on the rating plate.
1.2.2 Series specifications
MP 3 05 - EM / XX
MP MultiPress
(Multistage horizontal
centrifugal pump) design
Flow rate at optimal
efficeny Q [m
3
/h]
Number of impellers
Main voltage
DM 3 ~ 230/400 V
EM 1 ~ 230 V
Manufacturer's key
Pump Pump unit
Model Dimensions
H
H1 L L1
L2
L3 D1 D2
D3
1~230 V 3~400 V 1~230 V 3~400 V 1~230 V 3~400 V
MP mm
303 216 - 90 375 205 94 - 109,5 Rp1 Rp1 PG 13,5 -
304 216 216 90 423 253 94 94 157,5 Rp1 Rp1 PG 13,5 PG 11
305 216 192 90 423 253 88 88 157,5 Rp1 Rp1 PG 13,5 PG 11
603 216 192 90 375 205 94 94 109,5
Rp1
1
/4
Rp1 PG 13,5 PG 11
604 216 192 90 423 253 88 88 157,5
Rp1
1
/4
Rp1 PG 13,5 PG 11
605 224 206 90 448 253 104 88 157,5
Rp1
1
/4
Rp1 PG 13,5 PG 13,5
