Appendix en
Installation and operating instructions Wilo Motor T 12 ... 72 + EMU FA, Rexa SUPRA, Rexa SOLID 61
Connection values: max. 250V(AC), 2.5A, cosφ=1
ƒ Connect the PTC sensor via an evaluation relay. Relay “CM-MSS” is recommended
for this. The threshold is preset.
13.3.4.5 Leakage chamber monitoring
Connect the float switch using an evaluation relay! Relay “CM-MSS” is recommended
for this. The threshold is already pre-set.
13.3.4.6 Monitoring of motor bearing
The connection is made as described in the “Electrical connection” section.
13.3.4.7 Sealing chamber monitoring (ex-
ternal electrode)
ƒ Connect the external pencil electrode via an Ex-rated evaluation relay! Relay
“XR-4…” is recommended for this.
The threshold is 30kOhm.
ƒ The connection must be made using an intrinsically safe circuit!
13.3.4.8 Frequency converter operation
ƒ Type of converter: Pulse-width modulation
ƒ Continuous duty: 30Hz up to rated frequency (50Hz or 60Hz). Comply with the
minimum flow velocity!
ƒ Min. switching frequency: 4kHz
ƒ Max. overvoltages on the terminal board: 1350V
ƒ Output current on the frequency converter: max. 1.5times rated current
ƒ Max. overload time: 60s
ƒ Torque applications: quadratic pump curve
Speed/torque curves required are available on request!
ƒ Observe additional measures with regard to EMC regulations (choice of frequency
converter, filters, etc.).
ƒ Never exceed the rated current or rated speed of the motor.
ƒ It must be possible to connect the motor’s own temperature monitoring (bimetallic
strip or PTC sensor).
ƒ If the temperature class is marked as T4/T3, temperature class T3 applies.
13.3.5 Commissioning
DANGER
Risk of explosion when using non Ex-rated pumps!
Pumps without Ex rating may not be used in potentially explosive areas! There is a
risk of fatal injury due to explosion! Only use pumps which have the appropriate Ex
labelling on the rating plate within potentially explosive areas.
DANGER
Risk of explosion due to flying sparks in the hydraulics!
During operation the hydraulics must be flooded (completely filled with the fluid). If
the volume flow is interrupted or the hydraulics emerges, air cushions can form in
the hydraulics. If this happens, there is a risk of explosion, e.g. flying sparks due to
static charge! Dry-running protection must ensure that the pump is deactivated at
the appropriate level.
DANGER
There is a risk of explosion if dry-running protection is connected incor-
rectly!
If the pump is operated within an explosive atmosphere, the dry-running protection
must have a separate signal transmitter (redundant protection of the level control).
Pump deactivation must be performed with a manual reactivation lock!
ƒ The operator is responsible for defining the potentially explosive area.
ƒ Only pumps with corresponding Ex rating may be used within a potentially explosive
area.
ƒ Pumps with Ex rating must be labelled on the rating plate.
ƒ Do not exceed the maximum fluid temperature!
ƒ Dry running of the pump must be prevented! Ensure on-site (dry-running protec-
tion) that emerging of the hydraulics is prevented.
According to DINEN50495, a safety device with SIL level 1 and hardware fault toler-
ance 0 must be provided for category 2.
