Wilson Benesch The Actor - Technical Specifications

WILSON BENESCH
ACTOR LOUDSPEAKER.
SPECIFICATION.
DESCRIPTION:
FIBRE COMPOSITE TECHNOLOGY, LOUDSPEAKER.
TYPE:
FREE SPACE FLOOR STANDING.
RANGE:
FULL FREQUENCY;
30 Hz TO 20 KHz. +/- 2.5 dB 40 Hz TO 20kHZ.
IMP LOADING:
6 OHMS NOMINAL, 4.5 OHM MINIMUM. WITHIN 1-3 OHMS TOLERANCE 50 Hz TO
20KHz.
SENSITIVITY:
88dB / WATT, 2.83 v INPUT.
LOW FREQ LOADING:
BESSEL ALIGNMENT OF FOURTH ORDER REFLEX, DOUBLE CHAMBER
DIFFERENTIAL TUNING
CROSSOVER:
MINIMUM PHASE, PRIMARILY LOW ORDER 6dB / OCTAVE , SHORT SIGNAL PATH.
AIR CORE INDUCTORS, SELECTED POLYPROPYLENE CAPACITORS.
BASS DRIVER:
ISOTACTIC POLYPROPYLENE FERRITE DRIVE UNIT.
BASS-MID DRIVER:
ISOTACTIC POLYPROPYLENE FERRITE DRIVE UNIT.
TREBLE DRIVER:
SCAN 9300.
INTERNAL WIRING:
MULTI STRAND SILVER PLATED STRANDED COPPER, TEFLON JACKET.
INPUT:
BI WIREABLE.
POWER HANDLING:
200 w PEAK UNCLIPPED PROGRAMME.
MAXIMUM LEVEL:
112 dB AT 1 METRE.
INTERNAL VOLUME:
APPROX 44 LITRES.
SIZE:
HEIGHT: 1115 mm.
WIDTH: 230 mm.
DEPTH: 370 mm
WEIGHT: APPROX 26 Kg.
©
Copyright Wilson Benesch Ltd All rights reserved 1999
Wilson Benesch maintains an active and on going research and development program. As new technology is
realised these innovations are brought to our designs either in upgrade or in the form of new products.
