1
inlet and outlet con-
nection
7 Output curvy bar 13 Input curvy bar
2 Barrelhead 8 Connected bar 14
Joint of dirtiness en-
trance
3 Main body 9 Spray bar 15 Input bar
4 Light tube 10 Spray bar cover 16 Input cover
5 Draining Skep Cover 11 Dirtiness entrance 17 Sucking disc for fix
6 Draining Skep 12 Connected bar 18 pipe
Ceramic Ring Active Carbon Biochemical Cotton Bio-Ball
Filtermaterial
