1 Inlet and outlet con-
nection
7 Curved outlet tube 13 Curved inlet tube
2 Filter head 8 Connection tube 14 T-shaped dirty water inlet tube
3 Filter canister 9 Spray bar tube 15 Outlet tube
4 UV tube 10 Spray bar tube cover 16 Outlet cover
5 Filter cover 11 Dirty water inlet 17 Fixing suction cups
6 Filter baskets 12 Connecting tube 18 Flexible tubes
Cermaic rings Filter sponge Filter cotton Bio balls
© by WilTec Wildanger Technik GmbH Item 50192–50197, 50358, 50359 Page 10
http://www.WilTec.de
http://www.aoyue.eu 11 2020-1
http://www.teichtip.de
