19
7 5510077 Pulley, Spindle Step 1
8 5510078 Nut, Spindle 1
9 5510079 V-Belt 1
10 5510080 Pulley, Spindle, VS, Lower 1
11 5510081 Pulley, Spindle, VS, Upper 1
11A 5513673 Screw, Cap 1
11B 5513674 Nut, Hex 4
12 5510082 Bearing, Ball 1
13 5510083 Cover, Bearing 1
14 5510084 Lever, Speed Change 1
15 5510085 Bearing, Ball 2
16 5510086 Bushing 1
17 5510087 Bushing 1
18 5510088 Bolt, Hex 4
19 5510089 Washer 4
20 5510090 Housing, Bearing 1
21 5510091 Screw, Set 1
22 5510092 Shaft, Spindle Mid 1
23 5510093 Key 1
24 5510094 Key 1
25 5510095 C-Ring (Shaft) 1
26 5510096 Belt, Variable Speed 1
27 5510097 C-Ring (Shaft) 2
28 5510098 Cover, Spring 1
29 5510099 Spring
30 5510100 Pulley, Motor, VS, Lower 1
32 5510102 Key 1
33 5510103 Pulley, Motor, VS, Upper 1
34 5510104 Screw, Set 1
35 5510105 Bracket, Speed Change 1
36 5510106 Link 1
37 5510107 Shaft 1
38 5510108 C-Ring (Shaft) 1
39 5510109 C-Ring (Hole) 1
40 5510110 Bearing, Ball 2
41 5510111 Nut 2
42 5512114 Sleeve, Control Rod 1
43 5512115 Rod, Control 1
44 5510114 Pin Spring 1
45 5510115 Pin 1
46 5510116 Roller 1
47 5510117 Nut, Hex 1
48 5512116 Housing 1
49 5513675 Screw, Cap (M8x35) 2
50 5513676 Screw, Pan Head 6
51 5510121 Gear, Helix 1
52 5510122 Gear, Worm 1
53 5510123 Bearing, Thrust 1
54 5510124 Bushing 1
55 5513677 Set Screw 1
56 5510126 Wheel, Hand (includes #58) 1
57 5510127 Ring, Retaining 1
58 5510126 Grip, Hand 1
59 5510129 Screw, Set 1
60 5513678 Assy., Pulley Cover (incl 1
60A,60B,60C,60D)
60A 5513679 Bracket, Nameplate 1
60B 5513680 Plate, Cover 1
60C 5513681 Screw, Cap 2
60D 5513682 Bracket, Plate 1
61 5510131 Bearing, Thrust 1
62 5510132 Shaft 1
63A 5513683 Screw, Cap 2
64A LED Display
5513519 115/230 LED Display
5513736 220/440 LED Display
65 5513690 Plate, Face 1
66 5513685 C-Ring (Hole) 1
67 5510137 Screw, Round Head 4
76 5511848 Knob 1
77 5514634 Set Screw (M3x8) 1
78 5511849 Cover 1
79 5513354 Screw 2
80 5510344 Motor 2hp 1ph 115/220V 1
5510345 Motor 2hp 3ph 220/440V 1
80A 5517320 Key, Square 1
80B 5517321 Washer, Flat 4
80C 5517322 Nut, Hex 4
81 Switch, Fwd/Rev 1
5517323 1 Phase
5517331 3 Phase
81A 5517324 Plate, Switch 1
81B 5517325 Label 1
81C 5517326 Cover, Label 1
82 5513356 Box, Switch 1
83 5513357 Screw 2
84 5513358 Nut, Hex 4
85 5513359 Screw 4
86A 5517327 Strain Relief 2
86B 5517328 Nut, Hex 2
87 5517329 Cord, Connection 1
88 5517330 Cord, Power 1
89 5513935 Assy., VS Spindle Pulley 1
90 5513934 Assy., VS Motor Pulley 1
91 Assy., Switch (includes 1
items 76-79,81-85)
5513355 1 Phase
5514716 3 Phase
Parts Listing — Drill Head — Manual Speed Control
(Models 2221VS and 2223VS)
Item Part
No. Number Description Qty
Item Part
No. Number Description Qty
To Next Page
