FRAME ASSEMBLY
CLIPPER 98630 06/13/00
22
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 OPEN
2 34357 1 FRAME, CLIPPER 12
3 39528 1 HOSE ASM, 1.5 BLK VAC X 15.5
4 41236 2 HUBCAP, 5/8" SHAFT
5 41351 1 HARNESS, MAIN, CLP/ADM
6 41354 1 HINGE, TANK TO FRAME
7 53640 1 MOTOR ASM, BRUSH CLP FAMILY
8 57030 10 NUT, 10-32 HEX NYLOCK
9 57245 3 NUT, 1/4-20 HEX NYLOCK SS
10 99809 2 FOAM TAPE, 1/8 THK X 3/4 1SDA
11 62761 1 PLATE, BRUSH MTR CLAMP
12 64099 1 PULLEY, 1.4 OD, 6GR, MICRO-V
13 73949 2 SPACER, HANDLE PIVOT
14 36081 2 GEAR, 40 TOOTH
15 70085 2 SCR, 1/4-20 X 1/2 PPHMS SS
16 70066 10 SCR, 10-32 X 3/4 PPHMS
17 OPEN
18 87013 2 WASHER, 1/4 ID X 5/8 OD SS
19 87025 2 WASHER, 1/4 LOCK EXT STAR SS
20 87018 10 WASHER, #10 X 9/16 OD
21 70074 2 SET SCR, 10-32 X 1/4 KCP
22 73197 1 STRAIN RELIEF, 90 DEGREE
23 OPEN
24 89114 2 WHEEL, 1-5/16 X 9.625 DIA
25 03107 1 AXLE, 5/8 X 17.06L
26 99667 10” HEAT SHRINK, 3/4 ID UL/CSA
27 73943 1 SEAL, FRAME/TANK
28 20041 1 CLAMP, 2.0" WORM GEAR
29 70671 6 SCR, 5/16-18 X 3.5 SHCS PLATED
30 87083 6 WASHER, 5/16 SPLIT LOCK PLTD
31 140354 1 BRKT, CLP HANDLE SUPPORT
32 140355 1 BRKT, CLP HANDLE SUPPORT LT
33 70271 2 SCR, 1/4-20 X 1/2 HHCS PLTD
34 70057 2 SCR, 1/4-20 X 1 PPHMS SS
35 66052 1 PIN, ROLL 1/8” X 1.0”L
36 70697 1 SCR, ¼-20 X 1.25 PPHMS SS
37 57105 3 NUT, ¼-20 HEX W/ STAR WASHER
To Next Page
