BRUSH ASSEMBLY
CLIPPER 98630 04/10/03
24
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 03110 1 AXLE, ROLLER
2 04084 1 ADAPTER, BRUSH BRG.
3 09019 2 BEARING, 1.125ODX.500IDX.375
4 11045 1 BELT, 180J6 MICRO-V
5 12032 1 BRUSH, 18L X 3.38OD
6 140343 1 BRKT, BRUSH PULLEY
7 140351 1 BRKT, BRUSH HEIGHT
8 34357 REF FRAME, CLIPPER 12
9 36192 2 GUARD, THREAD
10 41346 1 HOUSING, BRUSH, 18"
11 50998 1 LABEL, BRUSH HEIGHT
12 51311 1 LINKAGE, ASM, BRUSH HEIGHT
13 51312 1 LINKAGE ASM, ROLLER SUPPORT
14 51314 2 LINK, ROLLER, FRONT
15 51317 1 LEVER, HEIGHT ADJUSTMENT
16 57030 4 NUT, 10-32 HEX NYLOCK
17 57271 2 NUT, 3/8 DIA CAP, TYPE PUSH PLT
18 62758 1 PLATE, BRUSH HOUSING RH
19 62759 1 PLATE, BRUSH HOUSING LH
20 62762 2 PLATE, AXLE RETAINER
21 64098 1 PULLEY, 2.2 OD, 6GR, MICRO-V
22 66192 1 PIN, ROLL 1/4 X 1.25L
23 67411 1 ROLLER, 1.9 DIA X 10.5 LG
24 70043 2 SCR, 10-32 X 5/8 PFHMS
25 70088 6 SCR, 10-32 X 1/2 PPHMS SS DL
26 70177 7 SCR, 10-32 X 1/2 FHMS SS
27 70232 2 SCR, 10-32 X 3/8 FHMS SS
28 70497 2 SCR, #10-24 X 1/2 SHCS
29 87016 4 WASHER, #10 LOCK EXT STAR SS
30 87018 6 WASHER, #10 X 9/16 OD
31 70675 4 SCR, 1/4-20 X. 5/8 THMS PLTD NP
32 12525 1 BRUSH, 18L X 3.38 OD G2 1000090717
33 67467 1 RING, TOLERANCE 7/8 ID X 1/2 W 1000090717
34 27805 1 CLIP, BEARING
35 29157 1 DRIVER, BRUSH
36 70737 1 SHLDR BOLT, 3/8 OD X 3/8 L SS NP 1000090717
37 67094 1 RING, 1/2 EXT. SNAP
38 66310 2 PIN, CLEVIS 1/4 X 1/2 PLTD
39 80604 2 COTTER, 1/4" RING
40 73966 1 SPACER, .81ID X 1.06OD, ALUM
41 64102 1 PULLEY ASM, BRUSH
42 29208 1 DRIVER ASM, BRUSH
43 12515 1 BRUSH ASM, 18 IN
44 05158 1 ADAPTER, BRUSH BRG. DIE CAST 1000090717
45 09137 2 BEARING, R6 3/8 ID 1000090717
46 47383 1 BRUSH BEARING ASM.
47 47416 REF KIT,BRNG/ADPTR EXTRCTR
