PUMP ASSEMBLY
CLIPPER 98630 04/10/03
26
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 22072 1 COUPLING, 1/4 ANCHOR W/1" HEX
2 22090 2 CONNECTOR, 1/8FPT X 1/4 TUBEQC
3 31072 1 ELBOW, SWIVEL, 1/4MPTX1/4TUBE
4 31074 1 ELBOW, SWIVEL,3/8MPTX3/8TUBEQC
5 44067 2 JET BODY, MINI PROMAX BODY
6 44068 2 JET, MINI PROMAX 9504
7 57030 2 NUT, 10-32 HEX NYLOCK
8 65201 1 PUMP ASM, 115V 100 PSI W/CONN 1000030022
9 66288 2 PLUG, 9/16 OD BLK NYLON
10 70386 2 SCR, 10-32 X 1.0 PPHMS
11 70011 2 SCR, 1/4-20 X 5/8 HHCS SS
12 34355 1 FITTING,1/4 TUBE,"Y", QC
13 78419 1 TEE, 3/8 MPT X 3/8 TUBE, QC
14 84160 1 VALVE ASM,SOLENOID CLP FAMILY
15 87191 2 WASHER, 1/4"IDX1.0OD. FLAT SS
16 87018 4 WASHER, #10 X 9/16 OD
17 87192 2 WASHER, 7/16 X 3/4 X .19RUBBER
18 56014 1 NIPPLE, 1/4 CLOSE
19 56012 1 NIPPLE, 1/4 FPT QD
20 31076 2 ELBOW, 1/4 MPT X 3/8 TUBE, QC
21 70162 2 SCR, 10-32 X 3/8 PPHMS SS
22 - - OPEN
23 880278 1 WIRE, 22" GRN/18 76011 X 76011
24 39529 1 HOSE, 3/8 URETHANE X 29"
25 39530 1 HOSE, 3/8 NYLON X 6"
26 39531 3 HOSE, 1/4 URETHANE X 6"
27 73963 1 SCREEN, INTAKE
28 31022 1 ELBOW, 1/8NPT STREET
29 39551 1 HOSE, 3/8 NYLON X 29”
30 65183 REF PUMP ASM, 115V 100 PSI SHURFLO X-REF TO 47306
To Next Page
