Windsor Clipper CLP12 User Manual

VACUUM SHOE ASSEMBLY
CLIPPER 98630 6/10/99
28
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 05016 4 ARM, VAC SHOE PARALLEL
2 27674 1 COVER, ACCESSORY PORT
3 57245 4 NUT, 1/4-20 HEX NYLOCK SS
4 70351 2 SCR, 10-32 X 3/8 HHTR W/STAR
5 70360 4 SCR, 1/4-20 X.75 PPHMS PHIL
6 70390 4 SCR, 1/4-20 X 1 FHCS PLTD
7 73958 8 SPACER, 3/8ODX.058WX.2814,CRS
8 85040 1 VAC SHOE, 18"
9 OPEN
10 87013 4 WASHER, 1/4 ID X 5/8 OD SS
11 87074 8 WASHER, WAVE 3/8ID X3/4D X.125
12 35171 1 GASKET, ACCESSORY PORT
13 73955 2 SPRING, EXT .38D X2.75L X.055W
