CONTROL PANEL ASSEMBLY
CLIPPER 98630 01/25/00
30
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 14020 1 TERMINAL BLOCK, 115V (3-4-3)
2 14700 1 BREAKER, 15A 250VAC 50VDC
3 14832 1 BREAKER, 6A VDE CIRCUIT
4 14942 2 BOOT, 3/8 CIRCUIT BREAKER
5 41181 2 HOUSING, CLP HANDLE PIVOT
6 23679 1 CORD ASM, 14/3 X 22" YLW
7 27823 3 CONTACT, ELECTRICAL, FLAT
8 27824 3 CONTACT, ELECTRICAL, BENT
9 38285 2 HANDLE, CLP12 WELDED
10 38286 1 HANDLE, CONTROL PANEL FRONT
11 38287 1 HANDLE, CONTROL PANEL REAR
12 51114 2 LOCK, HANDLE POSITION
13 57153 2 NUT, 1/2-13HEXNYLOCK THIN PLTD
14 70067 2 SCR, 6-32 X 3/8 PPHMS
15 57040 2 NUT, 1/2 NPT CONDUIT
16 62766 1 PLATE, CONTROL PANEL, CLP/ADM
17 70330 4 SET SCR, 5/16-18 X 1/2 CONE PT
18 72130 2 SWITCH, SPST 2-POSITION ROCKER
19 72162 1 SWITCH, DPDT3-POSITION ROCKER
20 73505 1 STRAIN RELIEF, 1/2 NPT TRUMPET
21 78418 3 TRIGGER, SWITCH
22 50996 1 LABEL, CONTROL PANEL, CLP/ADM
23 57116 2 NUT, 6-32 W/STAR WASHER PLTD
24 57245 4 NUT, 1/4-20 HEX NYLOCK SS
25 70672 2 SCR, 1/2-13 X 4.75HHCS GR5 PLT
26 73307 2 SPRING, COMP .88D X1.4L X.100W
27 70406 9 SCR, #10 X 3/4 PPHST TYPE B
28 70127 6 SCR, 6-32 X 1/4 PPHMS SS
29 87026 2 WASHER, #6 LOCK EXT STAR SS
30 70105 4 SCR, 1/4-20 X 1.75 PPHMS SS
31 70235 2 SCR, 6-32 X 1.0 PH BLK NYLON
32 87086 2 WASHER, M10 X 30 PLTD
33 87100 2 WASHER, 3/8 ID INT.LOCK THIN
34 27371 2 CLIP, POWER CORD
35 41351 REF HARNESS, MAIN CLP/ADM
36 23086 1 CORD SET,14/3 SJTW-A X 50' YLW
37 67147 1 RING, 2" DIA SPLIT
38 73169 1 STRAIN RELIEF, CORD HOOK
39 27817 2 CABLE, .06 X 40, 0707, SS
40 70386 1 SCR, 10-32 X 1” PPHMS
41 57104 3 NUT, 10-32 W/STAR WASHER PLTD
42 87025 6 WASHER, 1/4 LOCK EXT STAR SS
43 67381 2 RING, 1/4 KLIP
44 51319 1 LEVER ASM, CLP HANDLE ADJ
45 70351 5 SCR, 10-32 X 3/8 HHTR W/STAR
46 27417 1 CORD, 99807 1/8 X 12"
47 500018 1 CARD, INSTRUCTION CLP12
48 20035 1 CLAMP, 7/16 DIA NYLON UL
49 50279 1 LABEL, GROUND SYMBOL
