Windsor Clipper CLP12 User Manual

RECOVERY TANK ASSEMBLY
CLIPPER 98630 06/10/02
34
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1A 20064 1 CLAMP, 2.0" WORM GEAR X .312 1000083387
1B 20002 1 CLAMP, 2.0” NYLON RATCHET
2 20041 1 CLAMP, 2.0" WORM GEAR
3 27670 1 CORD, DRAIN PLUG
4 27816 2 COVER, REC. TANK
5 28060 1 DOME, CLP FAMILY
6 34351 1 FLOAT SHUT-OFF
7 35230 1 GASKET, DOME
8 35232 2 GASKET, PORT COVER
9 39353 1 HOSE, 1.5 X 12.0 DRAIN
10A 41391 1 HOSE, INSERT 1000083387
10B 40019 1 HOSEBARB, 1.50 DOUBLE MCHD
11A 41390 1 HOSE, CAP 1000083387
11B 66227 1 PLUG, DRAIN HOSE
12 70114 6 SCR, #10 X 3/4 PPHST TYPE B
13 75262 1 TANK, CLP RECOVERY
14A 140408 1 BRKT, HOSE HOOK 1000083387
14B 140133 1 BRKT, RECOVERY HOSE MTG
15 27417 1 CORD, 99807 1/8 X 12"
16 500009 1 LABEL, WARNING
17 50993 1 LABEL, CLIPPER MAIN
18 28061 1 DOME ASM, CLP FAM
