10
Operations
Technical Specifications
ITEM DIMENSION/CAPACITY
Nominal power 1944 W
Rated Voltage 36 Volts DC
Rated Amperage 54 amps
Batteries 3 X12 Volt 205-234 AH @ 20 hr. rate
Battery Compartment Dimensions 21 in. x 16 in. x 17 in. tall (533mm x 406mm x 432mm)
Brush Motor .5 HP (373W)
Vacuum Motors 2 X .75 HP (560W)
Maximum flow rate of vacuum motors 78.0 cfm (36.8 liters per second)
Maximum suction of vacuum motors 71.8 inches of water (17.8 kPa)
Propelling Motor .75 HP (600 W)
Mass (GVW)
Ev185A-A = 1226 lbs, (557 kg)
J185H-AC = 1193 lbs. (542 kg)
J185P-AC = 1151 lbs. (523 kg)
Weight empty without batteries 418 lbs (190 kg)
Solution Control Variable with automatic shut-off in neutral
Solution capacity 25 gal (95 L)
Recovery capacity 27 gal (102 L)
Scrub brush diameter 4 inch (102 mm)
Scrub brush pressure Floating
Brush speed 1025 rpm
Tires 10 in. (254mm) Solid scrubber compound rear, urethane front
Extracting speed 1 .5 mph (.8km/hour)
Extracting speed 2 1.0 mph (1.7 km/hour)
Foundation Pressure 134 psi (923 Kpa)
Maximum Speed 4.1 miles/hour (6.5 km/hour)
Frame Construction Powder coated steel
Brake
Electrical parking brake,sets automatically whenever operator
steps off platform or engages emergency stop.
Minimum aisle u-turn width 64 in. (1630 mm)
Maximum rated climb and descent angle 10% (6 degrees)
Sound Pressure Level 69.0 dBA
86372820 Chariot 3 iExtract 26 Duo
