Windsor iExtract 26 Duo User Manual

11186372820 Chariot 3 iExtract 26 Duo
Wiring 2
* SEE SERIAL NUMBER PAGE
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86366610 2 HARNESS, VACUUM, CS26
2 86361910 1 HARNESS, PLATFORM PNL, CS26 PART OF 86372590
3 86366520 1 HARNESS, PLATFORM CS26 NOT SHOWN
4 86369820 1 HARNESS, DRIVE AND BRAKE ASM PART OF 86372590
5 86366620 1 HARNESS, HORN, CS26 PART OF 86372590
6 86372620 1 HARNESS, SOLENOID, IEXTRACT 26 PART OF 86372590
7 86372640 1 HARNESS, VACUUM ACT, IEXTRACT 26 PART OF 86372590
8 86372650 1 HARNESS, DECK ACT, IEXTRACT 26 PART OF 86372590
9 86372630 1 HARNESS, BRUSH MTR, IEXTRACT 26 PART OF 86372590
10 86372590 1 HARNESS, MAIN, IEXTRACT 26 NOT SHOWN
11 86008760 1 CONNECTOR 175 DCA GRY W/O TERMS NOT SHOWN
12 86010850 1 WIRE, 4X20 RD CTERM X 5/16 RING
13 86010860 1 WIRE, 4X20 BK CTERM X5/16 RING
14 86391740 1
HARNESS, PUMP, OFF-AISLE,
iEXTRACT26
(4*) OPTION
15 86391730 1
HARNESS, RELAY/SWITCH, O-A,
iEXTRACT26
(4*) OPTION

Windsor iExtract 26 Duo Specifications

General

Brand	Windsor
Model	iExtract 26 Duo
Category	Floor Machine
Language	English
