12386372820 Chariot 3 iExtract 26 Duo
Onboard Charger
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86360460 1 CHARGER, SPE 36V 20A CBHF2
2 86371500 1 GASKET, .125 X .31 X 36.0
3 86369800 1 PLATE, OBC MOUNT
4 86371490 1 PAD, CONSOLE IEXTRACT 26
5 86255910 2 STANDOFF, 1/4-20 X 1.0 HEX INS
6 86006850 2 SET SCREWS, 1/4-20X 1.25L
7 86005710 4 NUT, 1/4-20 HEX W/STAR WASHER
8 86366080 3 STANDOFF, 10-32 X 1.0 NYL
9 86371410 8 SCREW, 10-32 X .75 TMS SS BLK
10 86005700 3 NUT, 10-32 HEXSTRW LK STL ZNPLT
11 86274460 2
SCREW, 1/4-20 X .375 HHCS LCSTL ZNPLT
NP
12 86005670 1 NUT, 1/2-14 CONDUIT LK STL ZNPLT
13 86256180 1 STRAIN RELIEF, 1/2 NPT (.48ID)
14 86361440 1 STRAP, CORD
15 86361430 1 BRKT, CORD
16 86363800 1 CORD ASM, 16/3 SJT X 6FT BLK
17 86005810 1 NUT 1/4-20 HEX NYLOCK SS
18 86371560 1 PLATE, OBC LOCK
19 86361080 1 METER, SPE CHARGER
20 86273740 1 SCREW, 1/4-20 x 1.5 HHCS SS
21 86005640 2 NUT, 10-32 HEX NYLOCK STL GR2 ZNPLT
22 86278470 2 STUD, #10-32 X 3/4 CLINCH
23 86267510 1 WIRE, 25" GRN/14 76010 X 76010
24 86371520 1 WIRE, 20", BLK/8, TERMINAL
25 86371530 1 WIRE, 20", RED/8, TERMINAL
26 86371540 2 WIRE, ASM, OBC INTERUPT
