5386372820 Chariot 3 iExtract 26 Duo

Brush Deck 1

* SEE SERIAL NUMBER PAGE

REF PART NO. QTY DESCRIPTION

SERIAL NO.

FROM

NOTES

1 86373280 1 RAIL, AGITATOR

2 86372730 1 PLATE, BRUSH GUIDE

3 86372040 1 NUT, 5/16-18 HEX ACORN, SS

4 86371750 - DRIVE, BRUSH DECK SEE PAGE 60

5 86371510 1 COVER, END CAP, BRUSH CLIP

6 86370500 2 BRUSH, EXTRACTOR, 4” OD X 26” L

7 86374910 1 EXTRUSION, DUAL 4" BRUSH, 26" (1*)

8 86369150 1 END CAP, BRUSH CLIP

9 86369070 1 MOUNT, SOLUTION MANIFOLD

10 86341310 2 BRKT, BRUSH DECK PIVOT

11 86339570 1 COVER, DRIVE HOUSING

12 86331810 12 WASHER, M5 SPL SS

13 86330990 1 WASHER, 5/16 INT STAR, SS

14 86327510 7 SCR, KA50 x 16, WN1412 A2 SS

15 86014990 7 SCREW, M5X20, SHCS, ISO4762, SS

16 86373070 2 ASM, BRUSH END, NON-DRIVE

17 86173330 10 WASHER, M5, FLAT, ISO7093, SS

18 86276070 18 SCREW, 5/16-18 X 3/4 CARRIAGE SS

19 86274290 2 SCREW, 10-32 X .375 PHPNHMS SS

20 86270830 3 NUT, 5/16-18 HEX NYLOCK SS

21 86010670 4 WASHER, 5/16 FLAT SS

22 86173350 7 WASHER, M5, FLAT, ISO7089, SS

23 86224630 2 SPRING, BRUSH CLIP

24 86196300 10 SCREW, M5-.8 X 12 HHCS SS

25 86374190 2 GASKET, .125 X .31 X 2.5
