Windsor iExtract 26 Duo User Manual

5986372820 Chariot 3 iExtract 26 Duo
Brush Deck Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86370830 4 SCREW, 5/16-18 X 2.0, PNH, MS, SS
2 86370120 4 SPACER, .319DX.75DX.75L,AL
3 86368240 6 NUT,5/16-18,FLGNYLOCK,SS
4 86277410 2 SCREW, 5/16-18 X .625 CARR SS
5 86276070 2 SCREW, 5/16-18 X 3/4 CARRIAGE SS
6 86271840 2 NUT, 5/16-18 HEX NYLOCK THIN SS
7 86010670 6 WASHER, 5/16 FLAT SS
8 86277130 2 SCREW, 5/16-18X1.00 CARRIAGE SS
9 86259410 2 WASHER, THRUST.51 ID X1ODX.063
10 86228990 2 BEARING,FLNGD,.314ID X.502OD
11 86270830 2 NUT, 5/16-18 HEX NYLOCK SS
12 86373190 2 BRKT, SPRING HANGER
