6186372820 Chariot 3 iExtract 26 Duo
Brush Deck Drive
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86370470 1 HUB, COUPLING, 18ES 1/2" D-BORE
2 86349800 1 SPACER, 15.9OD X 5.3ID X 11L
3 86349790 1 PLATE, SUPPORT
4 86343870 1 HOUSING ASM, BRUSH DRIVE
5 86343860 1 BELT, TWIN 5MM GT2, 15W, 130T
6 86343850 2 PULLEY, 32T 5MM GT, 15W
7 86343840 1 PULLEY, 18T 5MM GT, 15W
8 86343830 2 PULLEY ASM, 22T 5MM GT, 15W
9 86224660 1 SPRING, TENSIONER
10 86224170 2 SHAFT, 6.2MM BRUSH DRIVE
11 86223780 8 SCREW, M4-.7 X 8 SCHSET CUP STL BLKOX
12 86223520 3 RING, 28MM INT SNAP PHOSPHATE
13 86223490 3 RING, 10MM EXT SNAP, DIN 471
14 86215870 1 BRKT, TENSIONER ARM
15 86173350 4 WASHER, M5, FLAT, ISO7089, SS
16 86172950 1 SCREW, M5X12, SHCS, ISO4762, SS
17 86014990 5 SCREW, M5X20, SHCS, ISO4762, SS
18 86012830 1 SHAFT ASM, DRIVE 24"
19 86012790 2 SHAFT ASM, BRUSH DRIVE
To Next Page
