6586372820 Chariot 3 iExtract 26 Duo
Console
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86005620 1 NUT, 1/4-20 X .962 WELL
2 86199840 1 FLOAT SCREEN CAGE ASSY (SLIP)
3 86272020 2 NUT, 8-32 HEXTHIN NYLOCK SS
4 86361770 2 WASHER, 1/4 SAE FLAT SS
5 86361760 1 SCREW, 1/4-20 X 1.25 CARRIAGE SS
6 86361410 1 GASKET, SIGHT GLASS DOME
7 86360770 1 BRKT, RECOVERY TUBE
8 86360700 1 GASKET, .188 X .37 X 53.2
9A 86374120 1 CONSOLE, IEXTRACT 26
9B 86369060 1 CONSOLE, OBC, IEXTRACT 26 OPTIONAL - CEC26
10 86006530 2 SCREW, 1/4-20 X 1 PPHMS SS
11 86360260 1 SHAFT, .25 X 15.80, SS
12 86360140 1 BRKT, LID HINGE
13 86359560 1 GASKET, FLOAT SCREEN ADAPTER
14 86359220 1 GASKET, LID, 48.5"
15 86359100 1 LID, RECOVERY
16 86359090 1 ADAPTER, FLOAT SCREEN
17 86359050 1 DOME, SIGHT GLASS
18 86359020 1 BASKET, FILTER, RECOVERY TANK
19 86324210 2 SCREW, 1/4-20 X 5/8 BHCS BLK
20 86323300 1 WASHER, 1/4" RUBBER
21 86279610 2 WASHER, SEAL 1/4X5/8OD SS
22 86161800 1 LATCH, CONCEALED KEEPER
23 86277620 2 SCREW, 8-32 X .5 HHCS SS
24 86273750 1 SCREW, 1/4-20 X 5/8 HHCS SS
25 86010650 2 WASHER, #10 X 9/16 OD
26 86329570 2 SCR, 10-32 X 1.0 TORX SS BLK PLTD
27 86371490 1 PAD, CONSOLE IEXTRACT 26 USED WITH 9A
28 86374830 1 COVER, STEERING ACCESS
29 86371500 1 GASKET, .125 X .31 X 36.0
30 86371410 4 SCREW, 10-32 X .75 TMS SS BLK
