6986372820 Chariot 3 iExtract 26 Duo
Control Panel - Upper
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86362590 1 SWITCH, SPDT 3 POSN MOM, ARROW
2 86360690 1 PANEL, CONTROL UPPER, CS26
3 86358440 2 O-RING, 4MM ID, 1.5MM THK, BUNA-N
4 86358430 2 SCR, M4X12, FHMS, ISO7046, SS NP
5 86354870 1 SWITCH, ROTARY
6 86354810 1 GASKET, ROTARY SWITCH
7 86354560 1 BEZEL, ROTARY SWITCH
8 53217380 1 KNOB, SELECTION
9 86315470 1 METER, HOUR, LCD
10 86295200 2 ASM, BUTTON, BLACK, W/BEZEL
11 86292780 2 SWITCH,MICRO
12 86292590 1 SWITCH, E-STOP AKW CHARIOT
13 86255900 6 STANDOFF, 6-32 X 5/8 HEX NYL
14 86198460 2 CLAMP, 5/8 NYLON
15 86012670 1 METER, 36V BATTERY
16 86007190 1 SWITCH, KEY DPST
17 86005640 2 NUT, 10-32 HEX NYLOCK
18 63130140 1 SPRING ELEMENT
19 86367100 1 LED, WATER INDICATOR
