7386372820 Chariot 3 iExtract 26 Duo
Control Panel - Lower with Off-Aisle - For Models 10061780 & 10061790
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86370170 1 PANEL, LOWER. IEXTRACT 26
2 86370180 1 PICDUO ASSEBMLY, IEXTRACT26
3 86372840 1 CONTROLLER, I-DRIVE, IEXTRACT 26
4 86361520 4 CLIP, CABLE ENTRY
5 86361420 1 HINGE, PANEL
6 86360890 1 GASKET, .125 X .31 X 23.6
7 86360880 1 COVER, CONTROL BOARD
8 86369020 1 BREAKER, 60A 2 - POLE
9 86006620 2 SCREW, 6-32 X 1/4 PPHMS SS
10 86270920 4 NUT, 6-32 HEX NYLOCK SS
11 86275260 2 SCR, 4-40 X 1/2 PPHMS
12 86255910 1 STANDOFF, 1/4-20 X 1.0 HEX INS
13 86255900 2 STANDOFF, 6-32 X 5/8 HEX NYL
14 86006850 1 SCR, 1/4-20 X 1.25 SSSCU
15 86005710 4 NUT, 1/4-20 HEX W/STAR
16 86005640 2 NUT, 10-32 HEX NYLOCK
17 86006760 1 SCREW, 5/16-18 X .75 HHCS GR5 ZNPLT NP
18 86369480 1 BRKT, CABLE ATTACHMENT
19 86271910 1 NUT, 5/16-18 FLEX LK STL GRA COPLT
20 86295200 1 ASM, BUTTON, BLACK, W/BEZEL
21 86292780 1 SWITCH, MICRO
22 86251410 1 RELAY 15A 36V MINI
23 86279020 2 WASHER #6 LOCK EXT STAR SS
24 86255900 4 STANDOFF, 6-32 X 5/8 HEX NYL
25 86005700 2 NUT 10-32 W/STAR WASHER PLTD
