Windsor iExtract 26 Duo User Manual

8386372820 Chariot 3 iExtract 26 Duo
Platform
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86359080 1 PLATFORM, OPERATOR
2 86318010 1 PEDAL, HEEL
3 86318000 1 PEDAL, ACCELERATOR
4 86361170 1 PIN, DOWEL, .25D X 3.125", STEEL
5 86279170 6 WASHER, #10 X 1.0 FLAT
6 86172980 10 SCR, KA50X10,PT OHS,WN1412,PLTD
7 86254970 3 SPRING, COMP 18MMOD X 83 X 2
8 86327510 3 SCR, KA50 x 16, WN1412 A2 SS
9 86198440 6 CLAMP, 1/4 PLASTIC CABLE
10 86264930 3 CABLE TIE, 3.5" UL/CSA
11 86361060 1 BRKT, POT. ACCEL PEDAL
12 86311560 1 POTENTIOMETER ASM, LINEAR
13 86005810 2 NUT 1/4-20 HEX NYLOCK SS
14 86007010 2 SCREW 1/4-20 X 3 1/4 HHCS PLT
15 86327910 4 SCR, KA50X25, PT OHS, WN1412, PLTD
16 86007110 1 SWITCH, 25A SPST 125-250V SNAP
17 86361160 1 PLATE, SWITCH COVER
18 86264940 2 CABLE TIE, 11.38" UL/CSA
