8786372820 Chariot 3 iExtract 26 Duo
Solution System
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86373000 1 MANIFOLD ASM, IEXTRACT 26
2 86134850 2 WASHER, SPRNG LK, M4, DIN127B,SST
3 86371880 1 SCREW, 1/4-20 x .75 THUMB SS
4 86371860 1 COUPLING, QD, 1/2 BARBED
5 86371850 1 COUPLING, QD, 3/8 NPT
6 86371840 1 VALVE, BALL, 3/8FPTx1/2BARB
7 86371830 1 ELBOW, 3/8MPT x 3/8MPT, 90 DEG, BRASS
8 86010670 1 WASHER, 5/16 FLAT SS
9 86366100 1 VALVE, 36V SOL, 1/2 BARB
10 86264940 3 CABLE TIE, 11.38" UL/CSA
11 86282360 1 HOSE, 1/2 WIREBOUND X 28"
12 86280910 1 HOSE, 1/2 ID WIRE BOUND X 23"
13 86278910 2 WASHER, 3/8 ID X 7/8 OD SS
14 86276920 1 SCREW, 3/8-16x1
15 86276220 2 SCREW, 8-32 X .375 HHMS SS
16 86264930 1 CABLE TIE, 3.5" UL/CSA
17 86271930 1 NUT HEX NYL LOC 3/8-16
18 86233410 1 CLAMP, 3/4 DIA CUSHION .406DIA
19 86233150 4 CLAMP, 3/8 HOSE (D-SLOT)
20 86189050 1 NUT WELL 1/4-20 HD
To Next Page
