Windsor iExtract 26 Duo User Manual

9386372820 Chariot 3 iExtract 26 Duo
Tank
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86367250 4 WASHER, .344IDX1.130ODX.09T SS
2 86366450 1 GASKET, SOLUTION FILL
3 86362380 1 ELBOW, PVC, 3/4M X SOC SCH 40
4 86361920 1 TUBE ASM, RECOVERY INLET
5 86361780 1 LANYARD, 12" SS
6 86361770 2 WASHER, 1/4 SAE FLAT SS
7 86361760 1 SCR, 1/4-20 X 1.25 CARRIAGE SS
8 86360780 1 TANK, BLUE, CS26
9 86360650 1 BRKT, HOSE RETENTION
10 86360640 2 GASKET, 3.30 X 2.45 X .188
11 86360630 1 GASKET, MAIN TANK
12 86359060 1 BULKHEAD FITTING
13 86358680 1 CAP, CLEAN WATER
14 86354270 1 HOSE, RECOVERY DRAIN
15 86353950 1 HOSE, SOLUTION DRAIN
16 86327510 1 SCR, KA50X16, PT OHS, WN1412, A2 SS
17 86314080 2 NUT, DRAIN FITTING
18 86277480 2 SCR, 5/16-18X1/2 PTHMS SS
19 86276490 8 SCR, 5/16-18 X 5/8 HHCS SS
20 86271940 1 NUT, 1/4-20 ACORN SS
21 86010670 4 WASHER, 5/16 X 3/4 SS
22 86007970 1 STRAINER, 3/8 IN. NPT 60 MESH
23 86005620 1 NUT, 1/4-20 X .962 WELL
24 86002390 1 CLAMP, 1.75 WORM GEAR X .312
25 86002380 1 CLAMP, 2.25 WORM GEAR
