9586372820 Chariot 3 iExtract 26 Duo
Vacuum Shoe Lift
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86373600 2 SCREW, 5/16-18 X 2 HHMS SS
2 86372090 2 SPRING, EXT, 1.0 OD X 6.5L X .125W
3 86371660 1 BRKT, LIFT MOUNT
4 86371640 1 BRKT, ACTR MT, REAR
5 86371630 1 BRKT, ACTR MT, FRT
6 86371620 2 PLATE, LIFT LINK
7 86371610 2 PLATE, LIFT ARM
8 86371600 1 BRKT, SPRING CARRIAGE
9 86370120 4 SPACER, .319D X .75DX.75L, AL
10 86361760 2 SCREW, 1/4-20 X 1.25 CARR SS
11 86360310 6 NUT, 1/4-20 FLG SS NYL
12 86351350 2 WASHER, .260 X .625 X .031, NYL, BLK
13 86320880 1 ACTUATOR, 36VDC, 3.0" STK, 8.74 LNG
14 86279380 6 WASHER, 1/2 X 1 X .08 NYL
15 86279350 16 WASHER, 1/2 X .771 X .013 WV
16 86277500 4 SCR, 1/4-20 X 5/8 CARR SS
17 86277030 4 SCR, 5/16-18X1.25 CARRIAGE SS
18 86276710 4 SCR, 5/16-18 X 2.0 CARRIAGE SS
19 86273780 4 SCR, 1/4-20 X 3/4 HHCS SS NP
20 86270830 12 NUT, 5/16-18 HEX NYLOCK SS
21 86264930 2 CABLE TIE, 3.5" UL/CSA
22 86259420 8 WASHER, THRUST .51ID X 1 OD BRO
23 86259410 8 WASHER, THRUST .51 ID X1 OD X.063
24 86228990 4 BEARING, FLNGD, .314 ID X .502 OD
25 86228900 2 BUSHING, .252 X .503 X .75 FLG
26 86228840 8 BUSHING, .314 X .502 X .5 FLG
27 86201510 6 SPACER NYLON 1/4ID X 1/2 OD
28 86010670 12 WASHER, 5/16 FLAT SS
29 86010630 6 WASHER, 1/4 ID X 5/8 OD SS
30 86008650 2 PIN, COTTER RING 1/4 X .041 X .844
31 86006250 2 PIN, CLEVIS 1/4 X 1.75 STL ZNPLT
