Windsor iExtract 26 Duo User Manual

9786372820 Chariot 3 iExtract 26 Duo
Vacuum Shoe Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86374370 4 PIN, CLEVIS 1/4 X .5 SS
2 86373620 4 SHOULDER BOLT, 1/4 X .5L SS
3 86371820 2 BRKT, VAC SHOE LATCH
4 86371810 1 BRKT, VAC SHOE MOUNT
5 86346600 4 SPACER, .320 OD x .257 ID x .505L NY
6 86279380 2 WASHER, 1/2 X 1 X .08 NYL
7 86276860 2 SCREW, 3/8-16 X 1.75 SCHBTNHCS SS
8 86271870 2 NUT, 1/4-20 HEX NYLCK THIN SS
9 86271770 4 NUT, 10-24 HEX NYLOCK SS
10 86259770 2 WHEEL, 5"D X 1~ X .5~ID GRY
11 86228910 2 BUSHING, .377 X .502 X 1.25 FLG BRZ
12 86201510 2 SPACER NYLON 1/4ID X 1/2 OD
13 86007690 4 SPRING, EXT .50D X2.25L X.063W
14 86005630 2 NUT HEX NYL LOC-THIN SS 3/8-16
