9986372820 Chariot 3 iExtract 26 Duo
Vacuum Shoe
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86371770 1 O-RING, 3/16 DIA X 9.5 DIA FOAM
2 86371670 2 LATCH, VAC SHOE
3 86370760 1 BRACKET, VAC SHOE
4 86370680 1 COVER, VACUUM SHOE
5 86370670 1 BASE, VACUUM SHOE
6 86347910 4 SPACER. FLG .375ID x .44OD, NYL
7 86373650 2 SPACER, .192 X .500 X .188, NYL
8 86327510 5 SCREW, KA50 x 16, WN1412 A2 SS
9 86278360 2 SHOULDER BOLT, 3/8 X .5L SS
10 86275080 2 SCREW, 10-32 X .75 SCHCS SS
11 86270990 2 NUT, 10-32 HEX NYLOCK SS
12 86270830 2 NUT, 5/16-18 HEX NYLOCK SS
13 86173330 9 WASHER, M5, FLAT, ISO7093, SS
14 86010670 2 WASHER, 5/16 FLAT SS
15 86374590 2 WASHER, .20 X .45 X .04, NYL, BLK
