Windsor LB1500 - Page 19

DRIVE/PAD LOCK GROUP
LB1500 980101 03/08/03
5-6
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 70709 2 SCR, SET M8 X 1.25 X 8MM CUP POINT
2 87086 4 WASHER, M10 X 30 PLTD
3 70507 4 SCR, 3/8-16 X 3/4 HHCS GR5 PLTD
4 48041 1 KEY, 3/16 SQ X 7/8 CRS
5 64106 1 PULLEY, .625 X 3.45
6 87218 1 WASHER, M6 (20.5OD X 1.6T) PLTD
7 70505 1 SCR, 1/4-20 X 1.00 HHCS GR5 PLTD DL
8 14424 1 BELT, DRIVE 38 IN
9 67450 2 RING, 52MM INTERNAL SNAP
10 64107 1 PULLEY, BURNISHER
11 67449 1 RING, 20MM EXTERNAL SNAP
12 70719 3 SCR, M4 X 8MM LG PPHMS
13 09133 1 BEARING, 20MM X 52MM
14 27913 1 COVER, BEARING
15 66337 1 PAD DRIVER, 20 IN BURNISHER
16 51353 1 LOCK, PAD DRIVER BLUE
17 70720 3 SCR, #10 X 3/8 PPHST TYPE B
18 70201 8 SCR, 1/4-20 X 3/4 FHCS DL
19 09134 1 BEARING, 25MM X 52MM
20 03115 1 AXLE, PAD DRIVER
