Windsor LB1500 - Page 21

HANDLE GROUP
LB1500 980101 03/08/03
5-8
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 70686 2 SCR, M6 X 45 SHCS BLK
2 51326 1 LOCK, SAFETY HANDLE
3 73990 2 SPRING, EXT. .5OD X 3.5L
4 78437 1 TUBE, GRIP HANDLE
5 36196 2 GRIP, POLISHER HANDLE
6 51327 2 LEVER, SWITCH
7 57274 4 NUT, M6 X 1
8 500194 1 LABEL, WARNING
9 41363 1 HOUSING, POLISHER HANDLE FRONT
10 70689 2 SCR, M4.8 X 10 HHTF TYPE B
11 57275 3 NUT, M10 X 1.5 HEX NYLOCK PLTD
12 87086 3 WASHER, M10 X 30 PLTD
13 78544 1 TUBE ASM, HANDLE EXTND
14 67430 1 ROD, HANDLE ADJUSTMENT
15 87202 1 WASHER, BEARING (HANDLE ADJ)
16 66334 1 PIN, PIVOT HANDLE ADJUSTMENT
17 14344 1 BAR, HANDLE ADJUSTMENT
18 140393 1 BLOCK, HANDLE MOUNT
19 14434 2 BUMPER, BURNISHER HANDLE
20 70692 1 SCR, MID X 75 HHCS PLTD
21 41366 1 HOUSING, POLISHER HANDLE FRONT
22 70687 2 SCR, M6 X 50 SHCS BLK
23 38316 1 HANDLE, BRNSHR EXTND
24 730021 1 SPACER, POLISHER HANDLE
25 23206 1 CORDSET, 14/3 X 52” SJT BLK
26 730012 1 STRAIN RELIEF, 14/3 STRAIGHT
27 70701 1 SCR, M10 X 1.5 X 90 HHCS PLTD
