BRUSH DECK
86037780 EXTRACTOR 02/15/08
5
-
2
REF
PART
NO.
PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86173020 70916 5 SCR, M5 X 10, PHMS, ISO7045, SS
2 86217390 270146 1 COVER, PULLEY, BRUSH DECK
3 86215260 11051 1 BELT, HTD 5MM 69T 9 WIDE
4 86223780 70896 2 SET SCR, M4 X 6LG, CP BLK
5 86223300 64115 1 PULLEY, BRUSH
6 86214970 03124 1 AXLE, PIVOT, BRUSH DECK
7 86229020 09163 2 BEARING, BRUSH PLASTIC
8 86005640 57030 2 NUT, 10-32 HEX NYLOCK
9 86173330 87513 2 WASHER, M5, FLAT, ISO7093, SS
10A 86247110 53146 1 MOTOR, 115V BRUSH DRIVE 115V ONLY
10B 86306720 - 1 MOTOR ASM, 230V DC PM 230V ONLY
11 86217920 140893 1 BRKT, FLOATING BRUSH, 10 IN
12 86223490 67468 2 RING, 10MM EXT SNAP, DIN 471
13 86216430 140912 2 BUSHING, BRUSH PRESSURE
14 86216040 02506 1 BRUSH, CHEVRON, 10 IN
15 86173220 70954 2 SCR, M6X12 PHCS, 12.5MM HD,SS
16 86223350 64125 1 PULLEY, MOTOR
